2022 Magni HTH 10.10

The HTH 10.10 telescopic handler is ideal for moving large, bulky loads in complete safety. Able to lift up to 10 tonnes, it is compatible with a wide range of accessories, making it extremely versatile. Equipped with an RFID system which provides automatic recognition of the various attachments used, this telescopic handler is able to meet a wide range of applications in heavy industry. Its four-wheel drive system, three manoeuvring modes and high ground clearance makes it highly manoeuvrable on all terrains.

The standard machine configuration includes:

CAB
Comfort seat
Adjustable steering column
Analogue joypad
Heating
Air conditioning
FM/AM radio with USB and Bluetooth connectivity
USB Type-A (5 V) inputs

REAL TIME INFORMATION
Touchscreen, 7"
MCTS – Magni Combi Touch System on-board software
Automatic RFID tools recognition system
LMI – Load Moment Indicator
Onboard and remote integrated diagnostics

TECHNICAL SPECIFICATIONS
Q-Fit standard
Provision for platform
Two-line CAN BUS system
Automatic front and rear wheel alignment
Automatic parking brake
Mechanical battery cut-off in engine compartment
Electrical system: 24 V – IP67

Specifications:
o Lifting capacity: 10,000 kg
o Capacity at maximum height: 5,500 kg
o Lifting height: 9.50 m
o Reach: 5 m
o Engine: Deutz TCD 3.6 L4 - stage V
o Rated power: 100 kW (134 hp) 2.200 rpm
o Number of gears: 2/2
o Hydraulic system: 350 bar (Load Sensing)
o Length: 5.66 m
o Width: 2.55 m
o Ground clearance: 370 mm
o Unladen weight: 13,200 kg
o Travel speed: 40 km/h
o Climate control as standard: Yes
o Automatic attachment recognition: Yes
o Reversable fan drive: Yes
o Year: 2022
o Hours: 671
o 10T Fork Carriage
o Hook
